Upgraded Pipe Shrinking Machine

Main structure and properties

FH-B2 type upgraded pipe shrinking machine is a full gear reduction shrinkage machine; reduction by multiple groups of large modulus precision gear processing. This upgraded shrinkage machine, the transmission is silent, the torque is particularly large, solving the problem of both shrinking large and long tubes, and shrinking small and short tubes, is the shrinkage equipment applicable to every heat pipe manufacturer.

Main technical parameters

1. Universal shaft drive structure: reinforced double cardan shaft drive

2. Shrink pipe diameter(mm): 3-25

3. Shrink pipe length (mm): 100-6000

4. Shrink pipe speed: fixed speed/speed regulation

5. Die material: alloy, die steel

6. Number of Sections: 8,12,16,18

7. Voltage: 380V three-phase/220V three-phase/220V single-phase

8. Single/Total Power(KW): 1.1*Segment Number

9. Suitable for pipe: copper pipe, iron pipe, aluminium pipe, stainless steel pipe, composite pipe, etc.

10. Volume(mm): 2000*1600*1300(L*W*H)

11. Weight: 2500 KG
